We are a market leader in structured media with geometrically arranged corrugated sheets offering improved operation over saddle random media. Our proprietary media designs provide greater resistance to fouling than random or monolithic media.
Request a Quote Contact an Engineer
Ceramic
Glazed ceramic
Cordierite
| BLOCK DIMENSION | % VOID SPACE | SURFACE AREA | PACKING DENSITY | CRUSH STRENGTH | |
|---|---|---|---|---|---|
| FLEXERAMIC® Structured Packing TYPE 28 | 12 1/8 x 12 1/8 x 12 1/8 (+/- .25 in), 308 x 308 x 308 mm (+/- 6mm) | 77% |
98 ft²/ft³ 320 m²/m³ |
35 lbs/ft³ 560 kg/m³ |
150 psi 10.5 kg/cm² |
| FLEXERAMIC® Structured Packing TYPE 48 | 12 1/8 x 12 1/8 x 12 1/8 (+/- .25 in), 308 x 308 x 308 mm (+/- 6mm) | 79% |
63 ft²/ft³ 208 m²/m³ |
30 lbs/ft³ 478 kg/m³ |
67 psi 4.7 kg/cm² |
TER (Thermal Energy Recovery efficiency)
| 150 SCFM /ft2 | 200 SCFM /ft2 | 250 SCFM /ft2 | 300 SCFM /ft2 | 350 SCFM /ft2 | |
|---|---|---|---|---|---|
| FLEXERAMIC® 28 Structured Packing | 95.54% | 95.12% | 94.77% | 94.46% | 94.19% |
| 1" LPD® Random Packing | 93.46% | 92.86% | 92.35% | 91.91% | 91.53% |
| 1" FLEXISADDLE® Random Packing | 93.46% | 92.86% | 92.35% | 91.91% | 91.53% |
Pressure Drop (inches wc through inlet and outlet beds)
| 150 SCFM /ft2 | 200 SCFM /ft2 | 250 SCFM /ft2 | 300 SCFM /ft2 | 350 SCFM /ft2 | |
|---|---|---|---|---|---|
| FLEXERAMIC® 28 Structured Packing | 3.8" | 6.8" | 10.6" | 15.3" | 20.9" |
| 1" LPD® Random Packing | 4.7" | 8.3" | 13.0" | 18.8" | 25.7" |
| 1" FLEXISADDLE® Random Packing | 5.9" | 10.6" | 16.6" | 23.9" | 32.6" |
Conditions: based on two 8’ deep beds with 70°F inlet, 1500°F combustion, and 180 second switch time. Fuel is natural gas with 0% excess combustion air added.
FLEXERAMIC® structured packing provides 35% lower pressure drop as compared to 1” ceramic saddles at the same gas flow
Download Brochure
| FACE | STANDARD LENGTH | BLOCK SIZE | CELL COUNT | PASSAGE WIDTH | WALL THICKNESS | FREE AREA | SURFACE AREA | ALUMINA (AL2O3) |
|---|---|---|---|---|---|---|---|---|
|
5.91 x 5.91 in 150 x 150 mm |
11.8 in 300 mm |
25 Cell | 25 x 25 |
0.19 in 4.9 mm |
0.04 in 1.0 mm |
68% |
175 ft2/ft3 575 m2/m3 |
34% |
|
5.91 x 5.91 in 150 x 150 mm |
11.8 in 300 mm |
32 Cell | 32 x 32 |
0.15 in 3.7 mm |
0.04 in 0.9 mm |
63% |
215 ft2/ft3 710 m2/m3 |
34% |
|
5.91 x 5.91 in 150 x 150 mm |
11.8 in 300 mm |
40 Cell | 40 x 40 |
0.12 in 3.0 mm |
0.03 in 0.7 mm |
65% |
270 ft2/ft3 885 m2/m3 |
34% |
|
5.91 x 5.91 in 150 x 150 mm |
11.8 in 300 mm |
43 Cell | 43 x 43 |
0.11 in 2.8 mm |
0.03 in 0.7 mm |
65% |
290 ft2/ft3 950 m2/m3 |
34% |
Ceramic structured media combines the high heat capacity and low pressure drop of a honeycomb monolith shape with the chemical stability of the high alumina composition, making it particularly suitable for use in regenerative thermal oxidizer (RTO) and regenerative catalytic oxidizer (RCO) applications. FLEXILITHTM HA ceramic structured media is a cost-effective media for clean stream applications with effective particulate removal equipment upstream.
FLEXILITHTM CR ceramic structured media provides the most economical alternative and highest value option to optimize the performance of a regenerative thermal oxidizer (RTO) based on the lowest pressure drop provided by its unique geometry. With medium density, the FLEXILITHTM CR ceramic structured media provides a great solution for clean emission streams for effective particulate removal.
